Melt pump and screen changer

Performance characteristics

1. The double-column four-station screen changer is designed as a four-channel filter structure, and the four filter work at the same time, without interrupting the material flow, without interrupting the products, and realizing the non-stop screen change.

2. The design has the exhaust function of primer, which can prevent the influence of gas generated in the process of changing the screen on the downstream products.

3. The four-channel design greatly increases the filter area of the material and reduces the frequency of changing the screen, which is especially suitable for the application of recycled materials.

4. Reasonable structure design, simple operation, ideal effect, suitable for high capacity, high efficiency, large-scale extrusion equipment continuous operation.

Scope of application

Mainly used in chemical fiber, blown film, flat film, casting film, pipe, plate, wire, fiber manufacturing, pelleting and recycling granulation conditions.

Application case

Technical parameter

Type	Capacity (kg/h)	Dimension (mm)			Screen size		Heater
typc	kg/h	L1	L2	L3	Diameter (mm)	Area (cm2)	quantity	Voltage (v)	Power (w)
HK-DP-4R-120	260~760	180	1160	220	Φ100	78x4	6	230/400	1000/13000
HK-DP-4R-145	580~1400	225	1420	270	Φ125	123x4	6	230/400	2000/2400
HK-DP-4R-170	750~2000	260	1595	310	Φ150	177x4	6	230/400	3000/3500
HK-DP-4R-195	1350~3000	315	1890	380	Φ175	240x4	6	230/400	3500/4000
HK-DP-4R-220	1650~3800	350	2100	410	Φ200	314x4	10	230/400	3500/4000
HK-DP-4R-250	2100~5200	405	2395	460	Φ230	415x4	12	230/400	3500/4000
HK-DP-4R-280	4500~8500	450	2760	500	Φ250	490x4	12	230/400	4200/5000

The actual yield depends on the flow of the material, the filtration accuracy and the purity of the material. Parameters are subject to change without prior notice!

Heiko screen changer manufacturers

Zhengzhou Heiko is specialized in the production and sales of melt pumps, high temperature melt extrusion pumps, mesh changers, high precision filters and precision control systems (PLC) and other products. It is one of the earliest enterprises specializing in the production of melt gear pump and screen changer in China. The company independently develops and produces MP-S, MP-M, MP-H, MP-C and other series of high temperature melt gear pump products and HK-ACB, HK-SSP, HK-FSP, HK-DP and other series of screen changer products. Nowadays, mesh changers and melt gear pumps have been widely used in chemical fiber, granulation, plastic film, sheet, plate, profile, pipe, wire and cable, wire drawing, composite extrusion and other production lines, and the materials that can be processed almost cover most of the polymer materials, such as: PE, PC, PP, PVC, HIPS, PS, PA, TPUR, fluoropolymer, polysulfone, polyester, thermoplastic elastomer, rubber and thermal adhesive, etc.

The company integrates scientific research and production, and is committed to the development and promotion of melt gear pump and screen changer products. The company draws on the advanced technical experience of the same industry at home and abroad, and strives to create a professional melt pump manufacturer with the best products, the lowest price and the best service.
